Cicada Audio BDA1400.4D - 4 Channels x 350 watts @ 2 Ohm Amplifier





Product details

The Cicada Audio BDA1400.4D 4-channel amplifier boasts 4 channels delivering a staggering 350 watts each at 2 Ohms, setting a new standard for power and performance. It ensures your audio experience is nothing short of exceptional with bridged mono capability further expanding its versatility, delivering 2 x 600 Watts RMS into 4 Ohms at 12.5 Vdc and 2 x 700 Watts RMS into 4 Ohms at 14.4 Vdc. Featuring a frequency response of 20-20,000 Hz with THD less than 0.5%, it guarantees pristine sound reproduction across the spectrum. With compact dimensions, it packs immense power into a sleek package. Experience uncompromising audio quality and unmatched versatility with the Cicada Audio BDA1400.4D amplifier.

4 CHANNEL POWER AMPLIFIER
Requires 4 AWG Power Wire – HDPG4K

4 X 200 WRMS into 4 ohms @ 12.5 Vdc
4 X 225 WRMS into 4 ohms @ 14.4 Vdc
4 X 300 WRMS into 2 ohms @ 12.5 Vdc
4 X 350 WRMS into 2 ohms @ 14.4 Vdc

BRIDGED MONO – 2 CHANNEL
2 X 600 WRMS into 4 ohms @ 12.5 Vdc
2 X 700 WRMS into 4 ohms @ 14.4 Vdc
Frequency response – 20-20,000 +/- 3dB THD < 0.5%
Operating Voltage: 8V – 16V
Current Draw (Music): 50 A
Current Draw (Max): 220 A
Recommended Fuse (Music): 120 A
Total Efficiency: 79%
Damping Factor: 200
SNR: 91dB
Crossover LPF/FULL/HPF: 30 TO 300Hz
Slope:12dB per octave
Gain: 0.2V – 12 Vac
Turn-On Configuration: REM/DC
THD + N (10% Rated Power): 0.1%
Product Dimensions (Inches / Millimeters): 7.5 x 5.4 x 2.1 in / 190 x 137 x 54 mm
