Description
Features
- Conformal PCB Coating
- CHM- Collective Heat Management
- ACT – Adaptive Crossover Technology
- APC – Audio Protection Circuit
- Full Range Class “D” Circuitry
- 4 Gauge
Specifications
| Rated Power @14.4 Volts | |
|---|---|
| 4 x 150 Watts @ 4Ω | |
| 4 x 200 Watts @ 2Ω | |
| 2 x 200 Watts @ 4Ω Bridged |
Parameters
| Low Level Input | 6V - 0.2V |
| Crossover Selector | HPF / F / LP |
| High Pass Filter (@ 12dB Slope) | Variable 40Hz ~ 3Kz |
| Low Pass Filter (@ 12dB Slope) | Variable 40Hz ~ 3Khz |
| Minimum Working Impedance | 2 Ohm Stereo or 4 Ohm Bridged |
| Working Voltage | 12 - 15 Volts |
Description
Introducing the DB Drive MOTO400/4: WDX MOTO 4 Channel Amplifier, the powerhouse you've been waiting for! Get ready to experience a whole new level of audio performance that will leave you breathless. This Class D amplifier is packed with incredible features that make it a force to be reckoned with. With a conformal PCB coating and collective heat management, this amplifier is built to withstand the toughest conditions, making it perfect for your power sports adventures. The adaptive crossover technology ensures crystal-clear sound reproduction, while the audio protection circuit guarantees the safety of your speakers. With a rated power of 4 x 200 Watts at 2Ω, this amplifier delivers a thunderous sound that will rock your world. Don't settle for anything less than extraordinary - unleash the power of the DB Drive MOTO400/4 today and experience music like never before!
Product Manual
Product Manual PDF
