Description
Features
- ATC - Audiophile RCA Connectors
- ACT - Adaptive Crossover Technology
- High efficiency Class Full Range Class D Technology
- Direct Connect Speaker Terminals
- 4 Gauge Power Wire Inputs
- APC - Audio Protection Circuit
- SESI - Signal Evaluation Status Indicator
- CHM - Collective Heat Management
Specifications
- 4 x 125 Watts @ 4 ohms
- 4 x 250 Watts @ 2 ohms
- 4 x 500 Watts @ 1 ohm
- 4 ohms (Bridged): 2 x 1000 Watts
- Working Voltage: 12-15 Volts
- Frequency Response: 15 Hz - 20k Hz
- Signal to Noise Ratio: 96dB
- ACT - Variable Crossover HP/BP/LP
- Damping Factor: ≥200
- Low Level Input: 6V - 0.2mV
- Ch 1/2 High Pass Filter Variable: 15 Hz - 6k Hz
- Ch 1/2 Low Pass Filter Variable: 50 Hz - 2k Hz
- Ch 3/4 High Pass Filter Variable: 15 Hz - 6k Hz
- Ch 3/4 Low Pass Filter Variable: 50 Hz - 2k Hz
- Minimum working Impedance: 1 ohm stereo / 2 Ohms bridged
Description
Maximize your car audio with the DB Drive WDX PRO21000.4, a powerful 4-channel Class D amplifier built for high output and superior sound. Key Features: • Adaptive Crossover: Optimizes performance for tweeters, midranges, and midbass. • CHM: Keeps the amp cool during extended use. • SESI Circuit: Monitors output to prevent overdriving and protect your gear. • Large-Gauge Terminals: Support 4-gauge wiring for high-output systems. With 500 Watts per channel at 1Ω, the WDX PRO2000.4 delivers clear, powerful sound, elevating your audio experience.
