Description
Features
- 2.5″ Anodized aluminum high temperature voice coil
- Non-Pressed paper cone
- Double-stitched reinforced foam surround
- Dual poly-cotton dampeners
- Die-cast aluminum vented basket
- Rubber gasket trim ring
- Large gauge compression terminals
- Protective magnet cover
Specifications
| Dynamic Power Handling: 1500 Watts |
| Nominal Power Handling: 750 Watts |
| Impedance: Dual 2Ω Voice Coil |
| Resonant Frequency (fs): 37.64Hz |
| D.C. Voice Coil Resistance (Re): 2 x 2Ω |
| Mechanical Quality Factor (Qms): 3.44 |
| Electrical Quality Factor (Qes): 0.73 |
| Total Quality Factor (Qts): 0.60 |
| Equivalent Air Volume (Vas): 6.47 L |
| Mechanical Compliance of Suspension (CMS): 112.636 mm/N |
| Mass of Diaphragm/Coil (Mms): 158.77 g |
| Force Factor (BL): 14.38 |
| Sound Pressure Level (SPL): 78.6 dB |
| Dimensions |
| Outside Diameter: 8.78"/ 223 mm |
| Cutout Diameter: 7.36"/ 187.5 mm |
| Mounting Depth: 5.55"/ 141 mm |
Description
Designed for true bass enthusiasts, the WDX8G2R.2 subwoofers offer unmatched power and precision. • Featuring a custom mounting gasket for a perfect seal, eliminating rear-canceling waves for pure bass. • All-new dust caps and a custom-tooled aluminum basket provide durability, rigidity, and optimal heat dissipation. • The custom ribbed surround and High Excursion motor with Y35 ferrite magnets and high-temperature voice coils deliver deep, distortion-free bass. • Built for Bass: Power handling up to 1500 watts dynamic (750 watts nominal) The WDX8G2R.2 sets a new standard for earth-shaking bass. Ready to feel the difference?
