Description
Recommended Enclosure Specifications
For optimal performance with 700 watts RMS power, the following enclosure recommendations are ideal for achieving great sound in both sealed and ported configurations. Suitable for tight spaces like under seats or custom console installations.
Sealed Enclosure:
- 📏 Volume: 2.00 Cubic Feet NET
- 🔊 Resonant Frequency: 40Hz to 50Hz
- 📈 Down Point: 38Hz ±3dB
- ⚡ Full Excursion: Reached at 400 watts RMS
This sealed enclosure provides a smooth response with a balanced output, ideal for both sound quality (SQ) and overall performance.
Ported Enclosure Options:
-
📏 3.0 Cubic Feet NET
- 🔊 Port Size: 30 square inches x 16” long
- 📈 Tuning Frequency: 36Hz
- 🔊 Resonant Frequency: 48Hz
- 📈 SPL Increase: 5dB over sealed
This enclosure emphasizes hard-hitting bass with a sacrifice in sub-bass extension, suitable for SPL setups where you want to be heard.
-
📏 4.0 Cubic Feet NET (Recommended)
- 🔊 Port Size: 40 square inches x 18” long
- 📈 Tuning Frequency: 33Hz
- 🔊 Resonant Frequency: 44Hz
- 📈 SPL Increase: 5dB over sealed
This configuration offers the best balance of output and sub-bass extension, delivering both excellent upper-bass performance and extended sub-bass.
Choose the enclosure that best suits your audio needs and installation space for optimal performance and sound quality. 🎵📦
