Description
GLADEN GA 38 SG-NG 38 mm Sound-Quality Tweeter
Open-box closeout / final sale. The GA 38 SG-NG is GLADEN’s 38 mm sound-quality tweeter with a coated silk diaphragm and modular non-glued construction. Its larger diaphragm allows it to operate deeper into the midrange than conventional 25–28 mm tweeters, making it useful for demanding two-way and three-way front-stage layouts.
Manufacturer Specifications
- Model: GA 38 SG-NG
- Type: sound-quality tweeter
- Voice-coil diameter: 38 mm
- Impedance: 4 ohms
- Power handling: 60 W / 30 W RMS
- Recommended operating range: from 2,000 Hz
- Sensitivity: 95.0 dB at 2.83 V / 1 m
- Sensitivity: 91.3 dB at 1 W / 1 m
- DC resistance: 3.4 ohms
- Resonance frequency: 1,093 Hz
- Diaphragm: silk fabric
- Coil former: Kapton
- Hexacon grille
- GA 38 SG-NG version uses a non-glued modular tweeter capsule for flexible installation
Installation note: use appropriate DSP/high-pass protection and verify physical fitment before fabrication. Review open-box condition and included mounting parts before purchase.
Closeout & Special-Condition Items
What Each Product Condition Means
The exact condition for this item is identified in its product title and description. Contact SMS Car Audio before ordering when additional condition details are needed.
