Description
KICKER LX1300.7 — 7-Channel Class-D Amplifier
Choose the LX1300.7 when one chassis needs to cover a higher-channel-count system instead of forcing a second amplifier into the rack. The main four channels make 125 watts × 4 at 4 ohms or 150 watts × 4 at 2 ohms, the additional stereo pair makes 65 watts × 2 at either 4 or 2 ohms, and the dedicated sub channel reaches 700 watts at 1 ohm.
That extra 65-watt pair is the real reason to choose the 1300.7 over the LX1200.5. We can use the main channels for stronger door speakers or midbass, the smaller pair for tweeters/mids or another lower-power section, and the mono channel for the subwoofer. KICKER includes both the LX Control Center and LX Remote Control, so setup, diagnostics and day-to-day bass control stay inside the same platform.
Manufacturer Specifications
• Model: 51LX13007
• Channels: 7
• Main section, 4 ohms: 125 W × 4 RMS
• Main section, 2 ohms: 150 W × 4 RMS
• Main section, 4-ohm bridged: 250 W × 2 RMS
• Additional stereo pair: 65 W × 2 at 4 or 2 ohms
• Additional pair, 4-ohm bridged: 130 W × 1
• Sub channel: 300 W @ 4 ohms / 550 W @ 2 ohms / 700 W @ 1 ohm
• Full-range response: 20 Hz–20 kHz
• Sub response: 10 Hz–160 Hz
• Included: LX Control Center and LX Remote Control
• FIT+ high/low-level input capability: Up to 40 V
• Dimensions: 2-3/8 × 8-7/16 × 12-5/8 in.
Choose the LX1300.7 when one chassis needs to cover a higher-channel-count system instead of forcing a second amplifier into the rack. The main four channels make 125 watts × 4 at 4 ohms or 150 watts × 4 at 2 ohms, the additional stereo pair makes 65 watts × 2 at either 4 or 2 ohms, and the dedicated sub channel reaches 700 watts at 1 ohm.
That extra 65-watt pair is the real reason to choose the 1300.7 over the LX1200.5. We can use the main channels for stronger door speakers or midbass, the smaller pair for tweeters/mids or another lower-power section, and the mono channel for the subwoofer. KICKER includes both the LX Control Center and LX Remote Control, so setup, diagnostics and day-to-day bass control stay inside the same platform.
Manufacturer Specifications
• Model: 51LX13007
• Channels: 7
• Main section, 4 ohms: 125 W × 4 RMS
• Main section, 2 ohms: 150 W × 4 RMS
• Main section, 4-ohm bridged: 250 W × 2 RMS
• Additional stereo pair: 65 W × 2 at 4 or 2 ohms
• Additional pair, 4-ohm bridged: 130 W × 1
• Sub channel: 300 W @ 4 ohms / 550 W @ 2 ohms / 700 W @ 1 ohm
• Full-range response: 20 Hz–20 kHz
• Sub response: 10 Hz–160 Hz
• Included: LX Control Center and LX Remote Control
• FIT+ high/low-level input capability: Up to 40 V
• Dimensions: 2-3/8 × 8-7/16 × 12-5/8 in.
AMPLIFIER SYSTEM FIT
Where this fits in the build
An amplifier should be chosen around the channels, load, speaker or subwoofer plan, available electrical support and how hard the system needs to play.
Authorized Dealer — In-Store PurchasePlan aroundMatch usable channels and power to the actual speakers and load.
Match itPlan signal processing and gain structure before chasing wattage.
Finish itHigher output may require charging, battery and wiring upgrades.
