ARC Audio MOTO CX6 — 6.5-Inch Motorcycle/Powersports Coaxial Pair
You need more output than a normal car-door 6.5, but you do not necessarily need to jump straight to a horn-loaded speaker.
That’s where the MOTO CX6 makes sense.
At SMS, this is the 6.5-inch MOTO option we look at when the bike needs a strong, balanced coaxial that can live in a motorcycle or powersports environment. The shallower redesigned chassis helps with tight factory locations, while the sealed front face and floating tweeter layout give the speaker better protection from the environment than a conventional open coaxial design.
The big deal is usable output in the real location.
The CX6 is rated at 110 watts RMS and ARC publishes a 50 Hz–20 kHz frequency range. That gives us a speaker we can build around with the MOTO 800, PSM-Pro or another properly matched amplifier/DSP layout instead of treating the speaker like a factory replacement that just needs to make noise.
2014+ Street Glide? Check the grille.
ARC specifically notes that 2014+ Street Glide upper-fairing installations require the OEM metal grilles when using MOTO CX6 speakers. That is the kind of fitment detail we verify before the bike comes apart.
Manufacturer Specifications
- Model: MOTO CX6
- Sold as: Pair
- Nominal size: 6.5 inches
- Speaker design: Two-way coaxial
- Weather-resistant design: Yes
- Nominal impedance: 4 ohms
- RMS power handling: 110 watts
- Peak power handling: 260 watts
- Sensitivity: 92.5 dB
- Frequency response: 50 Hz–20 kHz
- Woofer cone: Carbon-filled polypropylene with sealed-front design
- Surround: Low-shore progressive S-shape rubber
- Spider: Progressive Nomex
- Woofer motor: Y35 ferrite, one-piece T-yoke design
- Voice coil: 1.25-inch glass-fiber former with high-temperature copper winding
- Tweeter: 25 mm damped PEI/Mylar dome
- Maximum outside diameter: 6.5 inches
- Motor diameter: 3.52 inches
- Mounting depth: 2.42 inches
- Flange thickness: 0.29 inch
- Cutout diameter: 5.57 inches
- 2014+ Street Glide note: OEM metal upper-fairing grilles required
You need more output than a normal car-door 6.5, but you do not necessarily need to jump straight to a horn-loaded speaker.
That’s where the MOTO CX6 makes sense.
At SMS, this is the 6.5-inch MOTO option we look at when the bike needs a strong, balanced coaxial that can live in a motorcycle or powersports environment. The shallower redesigned chassis helps with tight factory locations, while the sealed front face and floating tweeter layout give the speaker better protection from the environment than a conventional open coaxial design.
The big deal is usable output in the real location.
The CX6 is rated at 110 watts RMS and ARC publishes a 50 Hz–20 kHz frequency range. That gives us a speaker we can build around with the MOTO 800, PSM-Pro or another properly matched amplifier/DSP layout instead of treating the speaker like a factory replacement that just needs to make noise.
2014+ Street Glide? Check the grille.
ARC specifically notes that 2014+ Street Glide upper-fairing installations require the OEM metal grilles when using MOTO CX6 speakers. That is the kind of fitment detail we verify before the bike comes apart.
Manufacturer Specifications
- Model: MOTO CX6
- Sold as: Pair
- Nominal size: 6.5 inches
- Speaker design: Two-way coaxial
- Weather-resistant design: Yes
- Nominal impedance: 4 ohms
- RMS power handling: 110 watts
- Peak power handling: 260 watts
- Sensitivity: 92.5 dB
- Frequency response: 50 Hz–20 kHz
- Woofer cone: Carbon-filled polypropylene with sealed-front design
- Surround: Low-shore progressive S-shape rubber
- Spider: Progressive Nomex
- Woofer motor: Y35 ferrite, one-piece T-yoke design
- Voice coil: 1.25-inch glass-fiber former with high-temperature copper winding
- Tweeter: 25 mm damped PEI/Mylar dome
- Maximum outside diameter: 6.5 inches
- Motor diameter: 3.52 inches
- Mounting depth: 2.42 inches
- Flange thickness: 0.29 inch
- Cutout diameter: 5.57 inches
- 2014+ Street Glide note: OEM metal upper-fairing grilles required
OPEN-AIR / MOTORCYCLE / POWERSPORTS FIT
Where this fits in the build
These speakers have to work where wind, road noise, mounting space and exposure change the job. Match the driver to the actual location, output target, amplifier power and environment instead of treating it like a normal door-speaker replacement.
Authorized Dealer — In-Store PurchasePlan aroundConfirm mounting location, depth, cutout and how exposed the speaker will be.
Match itMatch efficiency, usable bandwidth and clean amplifier power to the output needed at speed or outdoors.
Finish itPlan crossover, mounting, wiring and electrical support with the complete open-air system.
