Description
The Beyma 10MFE is a 10-inch ferrite midbass and lower-midrange loudspeaker available in 4-ohm and 8-ohm versions. It is sold individually and is intended for custom mobile, motorcycle, powersports and multi-way loudspeaker systems.
Published data rates the 10MFE for 250 watts RMS, with 97 dB sensitivity, a 50 Hz–6.5 kHz frequency range, a 2.5-inch voice coil and 6 mm Xmax. Use a properly designed enclosure or rear chamber and appropriate crossover protection.
Specifications
| Model | 10MFE |
|---|---|
| Sold as | Single speaker |
| Nominal diameter | 10 inches |
| Impedance options | 4 ohms or 8 ohms |
| RMS power handling | 250 watts |
| Sensitivity | 97 dB, 1 W / 1 m |
| Frequency range | 50 Hz–6.5 kHz |
| Voice-coil diameter | 2.5 inches |
| Xmax | 6 mm |
| Cutout diameter | 9.6 inches |
| Mounting depth | 5.08 inches |
| Motor | Ferrite |
Select the impedance that matches the amplifier and final wiring configuration. Confirm enclosure volume and crossover settings for the intended installation.
