Description
CM65.2X — 6.5-Inch CM-X Component Mid-Bass — 2Ω — Pair
Choose CM65.2X when the front stage is being built as a real component system with a separate tweeter/horn and the amplifier is designed around a 2-ohm mid-bass load. Compared with CXXM65, CM-X steps up to 250W RMS, a CMC cone, die-cast basket and much more published upper-frequency extension.
SMS would use the 6.5-inch CM-X where fairing fitment still matters but the customer wants more output and crossover flexibility than the lower-power CXXM platform. This is not a full-range speaker by itself—the separate high-frequency driver and DSP/crossover plan are part of the system. Use CM65.4X when the amplifier/channel architecture calls for 4 ohms.
MANUFACTURER SPECIFICATIONS
• 6.5-inch dedicated component mid-bass pair
• 2Ω
• 250W RMS / 500W max per speaker
• 94 dB sensitivity
• Frequency response: 70 Hz–10 kHz ±3 dB
• Carbon Matrix Composite cone
• 2-inch Black Coat OFC voice coil
• N35SH neodymium motor
• Die-cast aluminum basket with Vortex Flow Venting
• Mounting depth: 2.3 in / 58 mm
• No integrated tweeter
Choose CM65.2X when the front stage is being built as a real component system with a separate tweeter/horn and the amplifier is designed around a 2-ohm mid-bass load. Compared with CXXM65, CM-X steps up to 250W RMS, a CMC cone, die-cast basket and much more published upper-frequency extension.
SMS would use the 6.5-inch CM-X where fairing fitment still matters but the customer wants more output and crossover flexibility than the lower-power CXXM platform. This is not a full-range speaker by itself—the separate high-frequency driver and DSP/crossover plan are part of the system. Use CM65.4X when the amplifier/channel architecture calls for 4 ohms.
MANUFACTURER SPECIFICATIONS
• 6.5-inch dedicated component mid-bass pair
• 2Ω
• 250W RMS / 500W max per speaker
• 94 dB sensitivity
• Frequency response: 70 Hz–10 kHz ±3 dB
• Carbon Matrix Composite cone
• 2-inch Black Coat OFC voice coil
• N35SH neodymium motor
• Die-cast aluminum basket with Vortex Flow Venting
• Mounting depth: 2.3 in / 58 mm
• No integrated tweeter
OPEN-AIR / MOTORCYCLE / POWERSPORTS FIT
Where this fits in the build
These speakers have to work where wind, road noise, mounting space and exposure change the job. Match the driver to the actual location, output target, amplifier power and environment instead of treating it like a normal door-speaker replacement.
Plan aroundConfirm mounting location, depth, cutout and how exposed the speaker will be.
Match itMatch efficiency, usable bandwidth and clean amplifier power to the output needed at speed or outdoors.
Finish itPlan crossover, mounting, wiring and electrical support with the complete open-air system.
