Description
The Kicker CompQ 10-inch is a Q-Class round subwoofer available in dual 2-ohm and dual 4-ohm versions. Kicker recommends 400–800 watts RMS of amplifier power.
A one-piece SoloKon cone with 360-degree back bracing, ribbed Santoprene surround, BlueLace progressive-roll spider and Forced-Air Cooling support controlled high excursion and thermal durability in sealed or vented enclosures.
Specifications
| Models | 51CWQ102 and 51CWQ104 |
|---|---|
| Nominal size | 10 inches / 25 cm |
| Voice-coil configurations | Dual 2 ohms or dual 4 ohms |
| Recommended amplifier power | 400–800 watts RMS |
| Frequency response | 25 Hz–100 Hz |
| Sensitivity | 82.6 dB for the 2-ohm model; 82.7 dB for the 4-ohm model |
| Outside diameter | 10-1/2 inches |
| Mounting cutout | 9-3/16 inches |
| Mounting depth | 6-1/4 inches |
| Recommended sealed volume | 0.66–1.0 cubic foot |
| Recommended vented volume | 1.25–1.75 cubic feet |
Features
- One-piece SoloKon cone with full back bracing controls flex.
- Ribbed Santoprene surround supports long excursion.
- BlueLace progressive-roll spider controls cone movement.
- Forced-Air Cooling improves heat transfer through the motor structure.
- Dual 2-ohm and dual 4-ohm versions support multiple final-load configurations.
- Published enclosure ranges support sealed or vented system designs.
