Description
Description
The Kicker 46FHD is a solid-brass dual AFS fuse holder that divides a power feed into two separately protected amplifier or accessory circuits. It provides two serviceable fuse positions and accepts cable from 1/0 through 8 AWG.
Versa-Gauge™ connections accommodate multiple cable sizes, while single-wrench 5 mm hardware simplifies installation and maintenance. Each fuse must be selected according to the downstream cable and connected equipment it protects.
Specifications
| Model | 46FHD |
|---|---|
| Product type | Dual AFS fuse holder and distribution block |
| Construction | Solid brass |
| Cable range | 1/0–8 AWG input and output connections |
| Fuse positions | 2 |
| Protected circuits | 2 |
| Fuse format | AFS / mini-ANL / AFC style |
| Connector system | Versa-Gauge™ |
| Hardware | Single-wrench 5 mm |
| Application | Two-amplifier or split-power distribution and protection |
Features
- Creates two independently fused power circuits from one distribution point.
- Solid-brass construction supports dependable current transfer.
- Two serviceable AFS fuse positions protect separate downstream circuits.
- Accepts cable from 1/0 through 8 AWG.
- Versa-Gauge™ connections reduce the need for separate cable adapters.
- Single 5 mm wrench size simplifies installation and maintenance.
- Each fuse must be matched to the downstream cable and connected equipment.
