The Kicker 46FHS is a solid-brass single AFS fuse holder for inline protection of an amplifier power cable. It accepts cable from 1/0 through 8 AWG on both sides and provides one serviceable fuse position.
Versa-Gauge™ connections accommodate multiple cable sizes, while single-wrench 5 mm hardware simplifies installation and maintenance. The installed fuse rating must be selected according to the cable size, connected equipment and circuit design.
Specifications
| Model | 46FHS |
|---|---|
| Product type | Single AFS fuse holder |
| Construction | Solid brass |
| Cable range | 1/0–8 AWG input and output |
| Fuse positions | 1 |
| Fuse format | AFS / mini-ANL / AFC style |
| Connector system | Versa-Gauge™ |
| Hardware | Single-wrench 5 mm |
| Application | Inline amplifier power-cable protection |
Features
- Provides one serviceable fuse position for the main amplifier power circuit.
- Solid-brass construction supports dependable current transfer.
- Accepts cable from 1/0 through 8 AWG.
- Versa-Gauge™ connections reduce the need for separate cable adapters.
- Single 5 mm wrench size simplifies installation and maintenance.
- Compact inline design fits common engine-bay and equipment-rack layouts.
- Fuse rating must not exceed the safe capacity of the cable, holder or connected equipment.
