Description
The Kicker SoloX L7X 10-inch is a square competition subwoofer available in dual 1-ohm and dual 2-ohm versions. Kicker recommends 1,000–2,000 watts RMS of amplifier power.
A three-inch voice coil, triple-stacked ferrite motor, dual-spider suspension and Forced-Air Cooling support high excursion and sustained output. The cone, voice coil and spider are assembled as a field-replaceable unit that bolts into the motor and basket without adhesive.
Specifications
| Models | 49L7X101 and 49L7X102 |
|---|---|
| Nominal size | 10 inches / 25 cm |
| Voice-coil configurations | Dual 1 ohm or dual 2 ohm |
| Recommended amplifier power | 1,000–2,000 watts RMS |
| Frequency response | 25 Hz–100 Hz |
| Voice-coil diameter | 3 inches / 75 mm |
| Linear excursion, Xmax | 31.25 mm |
| Mounting cutout | 9-3/16 inches / 23.4 cm |
| Mounting depth | 9-9/16 inches / 24.3 cm |
| Published vented volume | 1.65 cubic feet / 46.7 liters, excluding port displacement |
| Published port opening | 2.5 x 11.25 inches |
| Published port length | 19.5 inches |
| Published tuning frequency | 36 Hz |
Features
- Square cone provides greater radiating area than a conventional round driver of similar width.
- Triple-stacked ferrite motor and three-inch voice coil support high-output operation.
- Forced-Air Cooling moves air through the motor structure for thermal management.
- Dual-spider suspension controls the moving assembly at high excursion.
- Field-replaceable cone, voice-coil and spider assembly installs without glue.
- Requires a correctly engineered enclosure, amplifier load, electrical system and protective filtering.
