Description
The Kicker SoloX L7X 18-inch is a competition-oriented square subwoofer designed for very large, high-output vented enclosures. It is available in 1-ohm and 2-ohm versions and carries a recommended amplifier-power range of 1,000–2,000 watts RMS.
A three-inch aluminum voice-coil former, triple-stacked ferrite motor, dual-spider suspension and Forced-Air Cooling support high excursion and sustained output. The bolt-in field-replaceable cone, voice-coil and spider assembly can be serviced without glue when the matching-impedance recone kit is used.
Specifications
| Series | SoloX L7X |
|---|---|
| Models | 49L7X181 and 49L7X182 |
| Nominal size | 18 inches / approximately 46 cm |
| Rated impedance options | 1 ohm or 2 ohms |
| Recommended amplifier power | 1,000–2,000 watts RMS |
| Frequency response | 18 Hz–100 Hz |
| Voice-coil diameter | 3 inches / 75 mm |
| Linear excursion, Xmax | 1.25 inches / 31.25 mm |
| Recommended vented volume | 7.5 cubic feet / 214.5 liters, excluding port volume |
| Recommended port opening | 6.5 x 19.5 inches |
| Recommended port length | 27.75 inches |
| Recommended tuning frequency | 28 Hz |
| Mounting cutout | 16.5 inches |
| Mounting depth | 13-3/16 inches |
| Serviceability | Field-replaceable cone/voice-coil/spider assembly |
Features
- Large square cone provides substantial effective radiating area.
- Triple-stacked ferrite motor and three-inch voice coil support high-output operation.
- Forced-Air Cooling moves air through the motor structure for thermal management.
- Dual-spider suspension supports controlled high excursion.
- Field-replaceable recone assembly installs without glue.
- Separate 1-ohm and 2-ohm versions support different amplifier configurations.
- Requires a correctly engineered enclosure, high-current electrical system and protective filtering.
