Description
The Kicker SoloX L7X 8-inch brings the SoloX square-subwoofer platform to compact high-output installations. It is available in dual 1-ohm and dual 2-ohm versions, with a recommended amplifier-power range of 400–800 watts RMS.
A 2.5-inch voice coil, ferrite competition motor, dual-spider suspension and Forced-Air Cooling support controlled excursion and thermal management. The recone assembly is replaceable, but unlike the larger L7X models, the 8-inch recone requires the specified adhesive and approximately one hour of cure time.
Specifications
| Models | 49L7X81 and 49L7X82 |
|---|---|
| Nominal size | 8 inches / 20 cm |
| Voice-coil configurations | Dual 1 ohm or dual 2 ohm |
| Recommended amplifier power | 400–800 watts RMS |
| Frequency response | 30 Hz–100 Hz |
| Voice-coil diameter | 2.5 inches / 63.5 mm |
| Linear excursion, Xmax | 20 mm |
| Mounting cutout | 7-1/16 inches / 17.9 cm |
| Mounting depth | 8-7/16 inches / 21.4 cm |
| Published vented volume | 1.0 cubic foot / 28.3 liters, excluding port displacement |
| Published port opening | 2.5 x 9 inches |
| Published port length | 23 inches |
| Published tuning frequency | 39 Hz |
| Recone installation | Requires specified adhesive and approximately one hour of cure time |
Features
- Compact square cone provides substantial radiating area for an 8-inch platform.
- 2.5-inch voice coil and ferrite motor support high-output operation.
- Forced-Air Cooling moves air through the motor structure for thermal management.
- Dual-spider suspension controls the moving assembly at high excursion.
- Replaceable recone assembly supports serviceability with the correct adhesive procedure.
- Requires a correctly engineered enclosure, amplifier load, electrical system and protective filtering.
REAL SMS L7X 8 BUILD
2020 Dodge Ram — KICKER Solo L7X 8s
The 2020 Dodge Ram was loaded with KICKER Solo L7X 8-inch subwoofers in a custom ported under-seat enclosure, retaining the factory space. See truck bass planning → · Enclosure builds
