Description
Description
The Recoil Audio PMB65.4 is a 6.5-inch, 4-ohm Echo Pro midbass speaker designed to add stronger upper-bass impact and lower-midrange authority to custom doors, rear decks, speaker pods and multi-way mobile-audio systems. Its carbon-fiber cone and large 2-inch voice coil are intended to combine rigidity, thermal capacity and controlled output.
The driver is rated for 300 watts RMS and 600 watts maximum power, with 91 dB sensitivity. The current manufacturer record does not publish a frequency-response range or mounting depth, so enclosure volume, crossover targets and physical fitment should be confirmed before fabrication.
Specifications
| Model | PMB65.4 |
|---|---|
| Series | Echo Pro |
| Nominal diameter | 6.5 inches |
| Transducer type | Pro midbass speaker |
| RMS power handling | 300 watts |
| Maximum power | 600 watts |
| Nominal impedance | 4 ohms |
| Sensitivity | 91 dB |
| Voice coil | 2 inches |
| Cone material | Carbon fiber |
| Published frequency response | Not listed in the current manufacturer record |
| Published mounting depth | Not listed in the current manufacturer record |
| System requirement | Rigid mounting or suitable rear chamber with high-pass and low-pass filtering |
Features
- Carbon-fiber cone provides a rigid, lightweight radiating surface.
- Large 2-inch voice coil provides substantial thermal capacity.
- 300-watt RMS rating supports high-output midbass systems.
- Designed for upper-bass impact and lower-midrange authority.
- 4-ohm impedance works with common mobile-audio amplifiers.
- Suitable for custom doors, rear decks and speaker pods.
- Requires rigid mounting and correctly selected crossover protection.
