Description
Sold individually. Each quantity of 1 includes one speaker spacer. Order quantity 2 if you need a pair.
The SMS Precision 6.5-Inch Speaker Spacer provides additional mounting depth or stand-off distance for compatible 6.5-inch speakers. It is intended for custom doors, factory-location upgrades, speaker pods and fabrication projects where the speaker basket or magnet needs more clearance from the mounting surface.
Eight thickness choices are available from 1/4 inch through 2 inches. The selected thickness must still preserve door-panel, window-track, grille, surround and magnet clearance, and the spacer should be sealed correctly to the mounting surface.
Specifications
| Product type | 6.5-inch speaker spacer |
|---|---|
| Nominal speaker size | 6.5 inches |
| Available thicknesses | 1/4, 1/2, 3/4, 1, 1.25, 1.5, 1.75 or 2 inches |
| Application | Door speakers, factory-location upgrades, pods and custom panels |
| Material | Not published in the current product record |
| Exact cutout and bolt pattern | Confirm with the selected speaker and mounting location |
| Sold quantity | One spacer per selected quantity |
| Installation requirement | Rigid attachment and an air-tight seal to the mounting surface |
Features
- Eight thickness options support different clearance requirements.
- Can move the speaker magnet away from window tracks or internal obstructions.
- Can position the speaker closer to the factory grille when the layout permits.
- Suitable for factory-location upgrades and custom fabrication.
- Spacer thickness should be selected only after checking all moving parts and trim.
- Proper sealing helps prevent acoustic leakage around the speaker basket.
