Description
The ARC Audio RS 3.0 is a matched pair of compact 3-inch raw midrange speakers for active two-way and three-way front-stage systems. The small frame and 1.38-inch mounting depth allow the driver to be used in dash, pillar, upper-door, and custom pod locations where a larger midrange cannot fit.
Its published operating range of 105 Hz to 18 kHz gives the system designer flexibility to use the RS 3.0 as a dedicated midrange or wideband driver, depending on installation angle, target output, and DSP crossover strategy. The pair is impedance-matched for consistent left- and right-channel integration.
The RS 3.0 is rated for 35 watts RMS, 65 watts maximum, and 89 dB sensitivity. It is a raw driver without an included passive crossover or grille, so filtering and protection must be provided by the system design.
Specifications
| Series | RS Series |
|---|---|
| Sold as | Matched pair |
| Speaker type | Raw midrange |
| Size | 3 inches |
| Nominal impedance | 4 ohms |
| RMS power handling | 35 watts |
| Maximum power | 65 watts |
| Sensitivity | 89 dB |
| Frequency response | 105 Hz–18 kHz |
| Mounting depth | 1.38 inches |
| Passive crossover included | No |
| Grilles included | No |
Features
- Compact 3-inch reference midrange pair.
- Matched left- and right-channel drivers.
- Designed for active two-way and three-way systems.
- Wide 105 Hz–18 kHz published response.
- Shallow 1.38-inch mounting depth.
- Suitable for dash, pillar, upper-door, and custom-pod locations.
- 4-ohm nominal impedance.
- Raw-driver format for external DSP or crossover control.
- No passive crossover or grille included.
Where the RS 3.0 Fits
The RS 3.0 is an optional dedicated midrange within an ARC RS system—not a requirement for every reference build. SMS adds it when the vehicle offers a strong dash, pillar, or upper-door location, or when the client wants custom fabrication that creates a worthwhile acoustic position.
When placement does not justify another driver, the RS 6.0 and RS 1.0 can be used as a complete active two-way front stage.
Common Pairing
RS active 3-way: RS 6.0 midbass + RS 3.0 midrange + RS 1.0 tweeter, each on independent DSP channels. Amplification may come from X2 800.8 DSP, Blackbird, Falcon, or a stand-alone ARC processor with separate amplifiers depending on power, channel count, packaging, and the rest of the system.
Installation Considerations
Midrange placement affects stage height, width, path-length relationships, and crossover behavior. SMS evaluates location and aiming before adding the RS 3.0, then establishes crossover, delay, level, EQ, polarity, and phase through measured tuning.
